KLDguitar assembled kits of guitar amp GT20HK

Features

·20 watts (rms) into 16 or 8 ohms
·Dual EL84s and three 12AX7s
·20w/10w selection
·2-channel preamp
·Pre- post-gain controls on lead channel
Normal volume control on clean channel
·3-band passive EQs(bass, middle, treble)
·Boost switch
·Footswitch selectable channel switching and reverb(select AUX)
·Speaker output jack :4,8,16ohm,2x8ohm,2x16ohm
·Spring Reverb
·DI out
·Power transform: 108 watt

CE(EN650065), Rohs, and C-tick

DIMENSION:  52(L)x23(W)x27(H)( packed)
·WEIGHT: 10kg(22lbs) (Unpacked),12kg( Packed)

KLDguitar  assembled kits project include :
1. Assembled kits of KLDguitar tube guitar amps and pedals. Clients can order any part of amps or effect pedals  made by kldguitar except bulk cabinet of amp, at almost any stage of assembly (for example, order the entire amplifier as a kit of sub-assembled components, including power transformers, output transformers, and "populated" PCBs already installed into a chassis).
2. Front and back panel board of amps and pedals, Customers can design your panel , KLDguitar help you made them  bu PVC or PC film .
3. Accessories of cabinets , KLDguitar provide high quality vinyl and tweed tolex , Grill cloth, and other accessories of cabinet to customers such as piping , handle etc.
4.Certifications: KLDguitar have CE, C-tick , Rohs Certifications. These certifications are important to any brands. These certifications can  be forwarded to your brand by cooperating with kldguitar easily

KLDguitar provided total solutions of tube guitar amp to customers who want start up  brand self . These solutions are based on experience from kldguitar OEM for bigger brands. They include assembled kits of tube guitar amp, accessories of  amp cabinet. Customers can select each part of guitar amps from tolex, grill cloth to assembled kits of tube guitar amp etc . The quality of these components are guaranteed. All of these let you build your brand amp easily
